VI2F-ALI600MA

30V 600MA POWER SUPPLY FOR VIDEO INTERCOM SYSTEM - 2 WIRE SYSTEM

2 WIRE TECHNOLOGY. Power supply unit for video door phone system in 3 DIN modular housing. Power supply 110 - 240 Vac@50/60 Hz. Output 30V 600mA. The device is protected against overload and short circuit. The device does not need to be configured. V44 EASY SYSTEM.

Commercial Features

Technical data ETIM

Manuals and downloads

Request information

Commercial Features

Commercial data

Code EAN13:	8008379504398
Standard packing:	1,00
Minimum packaging:	1,00
Code EAN13 min.pck.:	8008379504398
Length min.pck.:	230,00
Width min.pck.:	190,00
Height min.pck.:	70,00
Volume min.pck.:	3,05
Weight min.pck.:	180,00
Quantity min. order:	1,00
Reference Metel:	VIDEO INT. POWER SUPPLY 30V 600MA
Product status:	In Stock

Safety instructions

Safety instructions:
Guarantees and complaints:

Technical data ETIM

Mounting method:	DIN rail
Width:	59
Height:	90
Application:	Video
Depth:	49
Input voltage:	230
Output voltage:	30
Type of current:	DC
Frequency:	50 \| -
Max. output current:	600
Installation technique:	Bus system

Integrated door opening circuit:	No
Control function:	No
Service indication:	Si
Number of connectable participators:	1
Width in number of modular spacings:	3
Evaluation function:	No
With contact:	No
Degree of protection (IP):	IP40
Short-circuit-proof:	Si
Programming lock:	No

Manuals and downloads

Commercial Catalog page

Pagina catalogo Pag475:

Manuals

Manuale Utente V44 EASY_Rev.015:
User manual V44 EASY_Rev.015_EN:
Manuale Sistema V44 EASY_Rev.015:
System manual V44 EASY_Rev.015_EN:

DXF-Ingombro

INGOMBRO DXF (DXF):
VI2F-ALI600mA (PNG):
SOLIDO STL (STL):
SOLIDO STEP (STP):

Tagliando

VI2F-ALI600MA - ALIMENTATORE DI IMPIANTO - GAMMA 2 FILI:
Sistema videocitofonico 2 fili:
