TS-SMART18ANS

MONITOR WITH 18" TOUCH SCREEN DISPLAY FOR V44 SMART SYSTEM. LAN + WI-FI CONNECTION, BRUSHED BURNISHED ALUMINUM COLOR (ANS).

DOMINA SMART touch screen monitor with 18" color graphic LCD. Bi-material structure: burnished aluminum and glass with black frame. User-selectable color LED bar. It can be powered via a 48Vdc PoE switch or via a 24Vdc stabilized power supply. It can be interfaced with: 53AB-WBS webserver for home automation supervision, AF927PLUS and AF927PLUSTC burglar alarm control units, external video intercom stations from the IP V44 SMART range, IP cameras visible via RTSP protocol. Double wired network card + WI-FI. Supervision of commands with KNX protocol. Recessed installation on BL07P, BL07CG or BL07CGN boxes installed horizontally using the special bracket supplied. Dimensions (LxHxD): 399x278x54 mm.

Commercial Features

Technical data ETIM

Manuals and downloads

Request information

Commercial Features

Commercial data

Code EAN13:	8008379508969
Standard packing:	1,00
Minimum packaging:	1,00
Code EAN13 min.pck.:	8008379508969
Length min.pck.:	230,00
Width min.pck.:	190,00
Height min.pck.:	70,00
Volume min.pck.:	3,05
Weight min.pck.:	2200,00
Quantity min. order:	1,00
Reference Metel:	18" IP TOUCH SCREEN MONITOR - ANS
Product status:	In Stock

Safety instructions

Safety instructions:
Guarantees and complaints:

Reference laws and directives

RAEE CAT. 5.18 RIPRODUZ.SUONI:
AVEUE20250122_TS-SMART18ANS:

Technical data ETIM

Colour:	Black
Installation technique:	Network technology
Video driving:	Si
Screen diagonal:	457,2
Picture system:	PAL

Screen diagonal (inch):	18
Type of interface:	TCP/IP
Property picture system:	Colour
:	Si

Manuals and downloads

Commercial Catalog page

Pagina catalogo Pag479:
Pagina catalogo Pag521:
Pagina catalogo Pag415:

Manuals

Manuale installatore Sistema V44 SMART_Rev006:
User manual TS_SMARTxx_Rev002_EN:
System manual V44 SMART_Rev006_EN:
Manuale TS_SMARTxx_Rev003:
User manual TS_SMARTxx_Rev003_EN:

DXF-Ingombro

INGOMBRO DXF (DXF):
TS-SMART18.. (PNG):
SOLIDO STL (STL):
SOLIDO STEP (STP):

Tagliando

TS-SMART18ALS - TS-SMART18ANS Monitor videocitofonico 18'' Touch Screen - Gamma IP:

Software

TS-SMART18 V1.4.2_20241230 - Software per postazione interna IP TS-SMART18:
DATABASE ETS PER TS-SMART18xx:
